Description
⚡ Standard IPS System (Zigor 1KVA) with 12V 100Ah Lithium Battery
📊 Technical Data Sheet
| Category | Specification |
|---|---|
| System Type | Online IPS / UPS System |
| UPS Model | Zigor Volga NG 1KVA Online UPS |
| Capacity | 1KVA / 800 Watts |
| Technology | Online Double Conversion |
| Phase | Single Phase |
🔹 Input Specifications
| Parameter | Details |
|---|---|
| Input Voltage | 110V – 300V AC |
| Frequency | 40Hz – 70Hz |
| Power Factor | ≥ 0.99 |
🔹 Output Specifications
| Parameter | Details |
|---|---|
| Output Voltage | 230V ±1% |
| Frequency | 50Hz ±0.25% |
| Waveform | Pure Sine Wave |
| Efficiency | Up to 95% |
🔹 Battery Specifications (Lithium)
| Parameter | Details |
|---|---|
| Battery Type | Lithium Battery |
| Capacity | 12V 100Ah |
| Backup Time | 3 – 8 Hours (Depending on Load) |
| Charging Time | 3 – 5 Hours |
| Life Cycle | 2000+ Cycles |
🔹 Features
| Feature | Details |
|---|---|
| Technology | Online Double Conversion |
| Control System | Microprocessor Based |
| Display | LCD + LED Indicators |
| Alarm | Audible Alarm System |
| Start Mode | Battery Start without Mains |
🔹 Protection
| Protection Type | Available |
|---|---|
| Overload | ✔ |
| Short Circuit | ✔ |
| Over/Under Voltage | ✔ |
| Battery Protection | ✔ |
| Thermal Protection | ✔ |
🔹 Monitoring & Communication
| Feature | Details |
|---|---|
| Communication Port | RS232 / USB |
| Software | Monitoring Software Supported |
| SNMP | Optional |
| Display | Real-time Status |
🔹 Physical Information
| Parameter | Details |
|---|---|
| Design | Tower Type |
| Cooling | Smart Fan Cooling |
| Build Quality | Industrial Grade |
🔹 Applications
| Use Case |
|---|
| Office & Corporate |
| Home Backup |
| IT & Server |
| Medical Equipment |
| Industrial Use |
🔹 Warranty & Support
| Item | Details |
|---|---|
| UPS Warranty | 1 Year |
| Battery Warranty | 1 – 3 Years |
| Service | Installation & Maintenance Available |
✨ Reliable, Efficient & Long Backup Power Solution for All Applications
